Type-X EVO Rally Spec Bundle
Type-X EVO Rally Spec Bundle
EVOLUTION.
To us, evolution means more than just gradual improvement or progression, it is about the whole process; substantial refinement in the pursuit of excellence. One year after the announcement of the TYPE-X™ EVO 8.5” LED Driving Light, we announce the arrival of the TYPE-X™ EVO 7” LED Driving Light. With one eye on the future, we have set our sights beyond typical shapes with the creation of TYPE-X™ EVO, redefining auxiliary driving lights as we know them.
THE BEST OF BOTH WORLDS.
The TYPE-X™ EVO LED Driving Light has arrived in a separate dedicated flood and spot beam pattern, meaning you can mix and match, and have full control of your desired beam to suit your driving. Utilising a more efficient technology from CREE’s XP range of LEDs, TYPE-X™ EVO (pair) offers up to a staggering 1470m of light throw down the road, and up to a 140m of light spread laterally into the critical zones. With this staggered rally set up, you can have all the light you will need. The most popular combination is 2 x TYPE-X EVO 8.5" spots in the middle, and 2 x TYPE-X 7" EVO floods on either end.
THE BEST OF BOTH WORLDS.
The TYPE-X™ EVO LED Driving Light has arrived in a separate dedicated flood and spot beam pattern, meaning you can mix and match, and have full control of your desired beam to suit your driving. Utilising a more efficient technology from CREE’s XP range of LEDs, TYPE-X™ EVO (pair) offers up to a staggering 1470m of light throw down the road, and up to a 140m of light spread laterally into the critical zones. With this staggered rally set up, you can have all the light you will need. The most popular combination is 2 x TYPE-X EVO 8.5" spots in the middle, and 2 x TYPE-X 7" EVO floods on either end.
SHAPING THE FUTURE.
If you want to know what the future of driving lights looks like, you’re looking at it. This is where finely-honed bespoke craftsmanship and next-generation design meet. Minimalism and purity work in harmony creating curves that complement the future of automotive. TYPE-X™ EVO 7” LED Driving Light opens up a world of possibilities, allowing fitment in a wide variety of locations where real estate is limited, without compromising on performance. The silhouette has been carefully crafted, not only for looks, however, for maximum punch in a perfectly sized package that minimises height over alternative options on the market. This opens up class leading performance to a myriad of new situations where a smaller light would have been required.
THE NITTY GRITTY
Good genes run in the family.
TECH SPECS
Type-X™ Evo 7 Inch
| LED | 32 x CREE XP20 LED (each) |
| RAW LUMENS | 8,200 (each) |
| TESTED LUMENS | 7,000 (each) |
| AMP DRAW | 8.5A @ 12v / 4.25A @ 24V (each) |
| POWER DRAW | 95W |
| CANDELA | 207,000 Flood (each) 528,000 Spot (each) |
| BEAM PATTERN |
32 x 30° Spread 32 x 4° Pencil Beam |
| INGRESS PROTECTION | IP68 | Submersible up to 3m |
| COLOUR TEMP (CCT) | 5000K |
| LUMEN MAINTENANCE | 30,000 LM-80 |
| VOLTAGE COMPATIBILITY | 12v & 24v |
| WEIGHT | 2.35kg (each) |
| OPERATING TEMPERATURE | -40°C to 60°C |
Type-X™ EVO 8.5 Inch
| LED | 44 x CREE LED (each) |
| RAW LUMENS | 18,920 (each) |
| TESTED LUMENS | 11,920 (each) |
| AMP DRAW | 12.5A @ 13.2v (each) |
| POWER DRAW | 150W |
| BEAM PATTERN |
44 x 50° Spread 44 x 5.8° Pencil Beam |
| INGRESS PROTECTION | IP68 | Submersible up to 3m |
| COLOUR TEMP (CCT) | 5000K |
| VOLTAGE COMPATIBILITY | 12v & 24v |
| WEIGHT | 3.3kg (each) |
| OPERATING TEMPERATURE | -40°C to 60°C |
