Victron EasySolar-II 24/3000/70-32 MPPT 250/70 GX

The EasySolar-II 24/3000/70-32 MPPT 250/70 GX is the all-in-one solar power solution from Victron Energy. It integrates a MultiPlus-II inverter/charger, a SmartSolar MPPT-Tr solar charge controller, and a GX device with a 2 x 16-character display. These elements are prewired together inside a single unit, simplifying most installations and saving both time and money.

Features

• All-in-one solar power solution: integrates inverter/charger, solar charge controller, and GX device.
• Display and Wi-Fi: Monitor battery, inverter, and solar charge controller parameters. Access and change settings via Wi-Fi.
• Solar charge controller: The DC output of the SmartSolar MPPT is parallel wired with the DC connection of the MultiPlus-II inverter/charger.
• GX device: includes a BMS-Can interface, USB port, Ethernet port, and VE.Direct port.
• VRM app for Wi-Fi: Monitor and manage your Victron Energy system from your smartphone or tablet.
• VRM Portal: Free remote monitoring website that displays system data in a comprehensive graphical format.

Specifications

• Inverter/Charger:
  • Input voltage range: 19 – 33 V
  • Output voltage: 230 VAC ± 2 %
  • Frequency: 50 Hz ± 0.1%
  • Continuous output power at 25°C: 3000 VA / 2400 W
  • Continuous output power at 40°C: 2200 W / 1700 W
  • Peak power: 5500 W
  • Efficiency: 94%
  • Zero load power: 13 W
  • Charge voltage 'absorption': 28.8 V
  • Charge voltage 'float': 27.6 V
  • Maximum battery charge current: 70 A
• SmartSolar Charge Controller:
  • Maximum output current: 70 A
  • Maximum PV power: 2000 W
  • Maximum PV open circuit voltage: 250 V
  • Efficiency: 99%
  • Charge voltage 'absorption': 57,6 V
  • Charge voltage 'float': 55,2 V
• General:
  • Interfaces: BMS-Can, USB, Ethernet, VE.Direct, Wi-Fi
  • Operating temperature range: -20 to +45°C
  • Humidity: max 95%
  • Weight: 26 kg
  • Dimensions (HxWxD): 499 x 268 x 237 mm
