Victron MPPT SmartSolar 250/100-Tr VE.Can

The SmartSolar MPPT 250/100-Tr VE.Can is a highly efficient solar charge controller from Victron Energy. It uses the latest and fastest technology to maximize energy harvest from solar panels by intelligently driving the process to achieve full charge in the shortest possible time. The SmartSolar ensures optimal performance, even in low light conditions, and maintains battery health, extending its life.

Features

• MPPT: Ultra-fast maximum power point tracking to enhance energy harvest.
• Remote Control: Manage and configure the charger remotely over Bluetooth via the VictronConnect App.
• Daisy Chain: Connect with additional VE.Can SmartSolar chargers for synchronized charging.
• Remote Monitoring: Access the full power of your solar charger(s) through the Victron Remote Management Portal (VRM) when connected to the internet.
• Efficiency: Outstanding conversion efficiency with no cooling fan. Efficiency exceeds 98%.
• Protection: Extensive electronic protection features, including over-temperature protection, PV short circuit, and reverse polarity protection.
• Bluetooth: Bluetooth Smart built-in for wireless setup, monitoring, and updates.
• VE.Can: Synchronize up to 25 units with VE.Can.
• VE.Direct: For a wired data connection to other devices.

Specifications

• Battery Voltage: 12/24/48V Auto Select (software tool needed to select 36V)
• Rated Charge Current: 100A
• Maximum PV Short Circuit Current: 70A
• Maximum PV Open Circuit Voltage: 250V
• Maximum Efficiency: 98%
• Protection: PV reverse polarity, PV short circuit, PV reverse current, Over temperature
• Operating Temperature: -30°C to +60°C (full rated output up to 40°C)
• Data Communication Port: VE.Direct & VE.Can

Shipping

• Dimensions (HxWxD): 130 x 186 x 70 mm
• Weight: 1.25 kg
