Victron MultiPlus-II 48/8000/110-100

MultiPlus-II 48/8000/110-100 Inverter/Charger

The MultiPlus-II is a multifunctional inverter/charger with all the features of the MultiPlus, plus an external current sensor option which extends the PowerControl and PowerAssist function to 50A resp. 100A. It is ideally suited for professional marine, yachting, vehicle, and land-based off-grid applications. It also has built-in anti-islanding functionality, and an increasingly long list of country approvals for ESS application.

Features

• PowerControl & PowerAssist
• Transfer switch with a maximum AC input current of 100 A
• Two AC Outputs with no break functionality
• Virtually unlimited power thanks to parallel operation
• On-site system configuring, monitoring, and control
• Remote configuring and monitoring via VRM Portal
• Compatible with both solar charger controllers and grid-tie inverters
• Built-in anti-islanding functionality

Specifications

• DC Input voltage range: 48V – 38-66 V
• Continuous output power at 25°C: 6400 W
• Continuous output power at 40°C: 5500 W
• Peak power: 15000 W
• Maximum efficiency: 95%
• Zero load power: 29 W
• Zero load power in AES mode: 19 W
• Zero load power in Search mode: 3W
• Charge voltage 'absorption': 57,6 V
• Charge voltage 'float': 55,2 V
• Storage mode: 52,8 V
• Max. battery charge current: 110 A
• Operating temperature range: -40 to +65°C (fan assisted cooling)
• Humidity: max 95% (non-condensing)
• Weight: 49 kg
• Dimensions (HxWxD): 677 x 363 x 206 mm
